The Hunter Pro-C Controller is a versatile‚ residential and light commercial irrigation system designed for efficiency and reliability. It offers 6- and 12-station models‚ expandable up to 16 stations with additional modules; Compatible with the EZ Decoder System and Solar Sync sensor‚ it ensures smart watering solutions for various landscapes.
Installation and Setup
The installation and setup of the Hunter Pro-C Controller require careful planning to ensure optimal performance. Begin by mounting the controller on a flat surface‚ such as a wall‚ using the provided screws or optional mounting bracket. Ensure the location is protected from direct sunlight and moisture. Next‚ connect the AC power supply‚ using a UL-listed 34″ conduit with a male adapter. The controller must be supplied with AC power and protected by a 15A rated overcurrent device.
After powering the controller‚ install the station modules. The Pro-C comes with a base module for up to 4 stations‚ and additional modules (PCM-300 or PCM-900) can be added to expand up to 16 stations. These modules are sold separately and must be compatible with the controller.
For proper functionality‚ connect the solenoid wires to the station terminals‚ ensuring correct polarity. If using a pump start relay‚ install it according to the manufacturer’s instructions and local electrical codes. Grounding the system is essential to prevent damage from electrical surges.
Finally‚ connect the sensors‚ such as the Solar Sync ET sensor‚ to enable smart watering features. Once all connections are secure‚ turn on the power and follow the on-screen prompts to complete the initial setup. Always refer to the manual for specific wiring diagrams and safety precautions to ensure a safe and successful installation.
Programming the Controller
Programming the Hunter Pro-C Controller is a straightforward process designed to customizable irrigation schedules. Begin by setting the current date and time on the controller‚ as this ensures accurate watering cycles. Next‚ define the watering schedule by selecting the desired start times and durations for each station. You can program multiple start times per day and adjust the watering duration based on specific landscape needs.
The controller allows for flexible scheduling‚ including daily‚ every other day‚ or cyclic (every 1-14 days) watering options. For manual operation‚ the One Touch feature enables quick activation of a single station or all stations‚ making it easy to test or run a cycle outside the programmed schedule.
Advanced features include compatibility with the Solar Sync ET sensor‚ which automatically adjusts watering schedules based on local weather conditions‚ ensuring water is used efficiently. For expanded control‚ the Pro-C Decoder Module (PC-DM) can be added‚ enabling two-wire operation and control of up to 32 stations.
When programming‚ ensure all stations are correctly assigned to their respective zones‚ and verify that the rain sensor (if installed) is properly connected to override irrigation during rainfall. Refer to the manual for detailed instructions on programming and troubleshooting common issues.
Features and Functionality
The Hunter Pro-C Controller is packed with advanced features designed to optimize irrigation efficiency and adapt to various landscaping needs. Its modular design allows for expandability‚ starting with a base module that supports up to 4 stations‚ with the ability to add modules for up to 16 stations. This flexibility makes it suitable for both small residential systems and larger commercial setups.
One of its standout features is compatibility with the EZ Decoder System (EZDS)‚ enabling hybrid conventional and two-wire operations. The Pro-C Decoder Module (PC-DM) can be added to control up to 32 stations‚ using the same EZ-1 decoders as other Hunter controllers like ICC2 and HCC. This scalability ensures the system can grow with your irrigation needs.
The controller also supports weather-based irrigation with the Solar Sync ET sensor‚ which calculates evapotranspiration rates and adjusts watering schedules accordingly. This smart feature helps conserve water and ensures plants receive the right amount of moisture. Additionally‚ the Pro-C is compatible with rain and freeze sensors‚ which automatically pause irrigation during unfavorable weather conditions.
With multiple program capabilities‚ the Pro-C allows for simultaneous operation of different watering schedules‚ making it ideal for complex irrigation systems. Its user-friendly interface and robust functionality make it a reliable choice for both residential and light commercial applications.
Troubleshooting Common Issues
When using the Hunter Pro-C Controller‚ occasional issues may arise‚ but most can be resolved with simple troubleshooting steps. One common problem is when the controller runs a watering cycle‚ but no water is released. This could be due to the water supply being shut off or a malfunctioning solenoid. Check the zone valves to ensure they are fully open and functioning properly. If the issue persists‚ inspect the solenoid for damage or debris.
Another frequent issue is the rain sensor interrupting irrigation. If the sensor is active but no rain is present‚ it may be faulty or improperly calibrated. Use the bypass switch on the controller to override the sensor temporarily. For long-term solutions‚ ensure the sensor is clean and correctly installed.
Electrical issues‚ such as the controller not powering on‚ can often be traced to incorrect wiring or a faulty circuit. Verify that the AC power is properly connected and that the overcurrent protection device (e.g.‚ a circuit breaker) is not tripped. Always use UL-listed conduit and wiring to prevent electrical hazards.
If the controller’s display is unresponsive‚ try resetting it by disconnecting and reconnecting the power supply. If the problem persists‚ consult the user manual or contact Hunter support for further assistance. Regular maintenance‚ such as cleaning sensors and checking connections‚ can help prevent many of these issues.
Compatibility with Other Systems
The Hunter Pro-C Controller is designed to integrate seamlessly with a variety of systems and accessories‚ enhancing its functionality and versatility. One notable compatibility feature is with the Solar Sync ET Sensor‚ which allows the controller to adjust watering schedules based on real-time weather conditions. This sensor calculates evapotranspiration (ET) rates‚ ensuring that irrigation is optimized for water conservation and plant health.
Additionally‚ the Pro-C Controller is compatible with the EZ Decoder System (EZDS)‚ which supports hybrid conventional and two-wire operations. By installing a Pro-C Decoder Module (PC-DM)‚ users can control up to 32 stations‚ leveraging the same EZ-1 decoders used with other Hunter controllers like the ICC2 and HCC. This expandability makes the Pro-C a flexible choice for both small and large irrigation setups.
The controller also works with the Hunter ET System‚ enabling advanced weather-based irrigation management. Furthermore‚ it is compatible with Hunter’s remote programming tools‚ such as the SRP (Smart Remote Programming) software‚ which allows users to program and manage irrigation schedules from a computer. This compatibility ensures that the Pro-C can adapt to various irrigation needs‚ making it a robust solution for residential and light commercial applications. Regular updates and support from Hunter ensure continued compatibility with emerging technologies and systems.
Models and Variants
The Hunter Pro-C Controller is available in several models and variants to cater to different irrigation needs. The base models include the 6-station and 12-station configurations‚ suitable for residential and light commercial applications. These models are designed for both indoor and outdoor installations‚ offering flexibility in setup and use.
One of the key variants is the Pro-C Decoder Module (PC-DM)‚ which enables compatibility with the EZ Decoder System (EZDS). This module allows the controller to manage up to 32 stations‚ making it ideal for larger irrigation systems. Additionally‚ the controller supports expansion modules such as the PCM-300 (adds 3 stations) and the PCM-900 (adds 9 stations)‚ providing scalability for growing irrigation requirements.
The Pro-C Controller also comes in variants that support advanced features like Wi-Fi connectivity for remote monitoring and programming. These models integrate seamlessly with Hunter’s smart irrigation solutions‚ such as the Solar Sync ET sensor‚ ensuring efficient water usage based on weather conditions.
For users seeking a more traditional setup‚ the Pro-C Controller is available in a non-decoder version‚ which operates as a standard irrigation controller without the need for advanced decoding systems. This variety ensures that the Pro-C Controller can meet the specific needs of various landscapes and irrigation systems.
Best Practices for Use and Maintenance
To ensure optimal performance and longevity of the Hunter Pro-C Controller‚ follow these best practices for use and maintenance. Regularly inspect the controller and connected components‚ such as solenoids and valves‚ to identify and address potential issues early. Keep the controller clean and free from dust and debris‚ which can interfere with its operation.
Always use UL-listed 34″ conduit with male adapters for AC wiring installations to meet safety standards. Ensure the controller is mounted in a location protected from direct sunlight‚ moisture‚ and extreme temperatures‚ which can damage the unit. For systems connected to a pump‚ install the controller at least 14.7 feet away from the pump and its relay to avoid electrical interference.
Seasonal maintenance is crucial. Before the first use in spring‚ test all stations and verify that the watering schedule is correctly programmed. In winter‚ drain the system and insulate exposed pipes to prevent freezing. Regularly update the controller’s software to access new features and improvements.
For troubleshooting‚ refer to the user manual or Hunter’s online resources. If issues persist‚ contact a licensed irrigation professional. Proper maintenance ensures efficient watering‚ reduces water waste‚ and extends the life of the Pro-C Controller. By adhering to these practices‚ users can enjoy reliable and efficient irrigation management.
